Parts for Tuxedo Lift TP15KF Carriage and Arm Restraint Detail

Above Ground / Surface Mount 2-Post Lifts – Tuxedo – TP15KF

Direct Fit™ brand Repair parts for Tuxedo Lift Model TP15KF are available from SVI.

SVI is the go-to supplier for repair parts for Tuxedo Lifts. Whether you need equalizer and lifting cables / chain, sheaves, slider blocks, hydraulic cylinders, seal kits, power units, overhead stop limit components, carriage locks and components, arm pins, height extensions and pads, or another part for your 2-post Tuxedo lift, SVI has what you need. We offer excellent pricing, top-notch customer service, and in-stock items usually ship out the same day.

Looking for a specific model breakdown or part? Contact SVI today!

Also see these additional breakdowns for Tuxedo Lift TP15KF:

Add to
Quote
Add to
Order
Item
SVI Part #
OEM #
QTY
Description

1
TP15KF-028
2
Carriage

2
TP15KF-018
8
Slider Block

3
TP15KF-031
4
Plastic Ball Handle

4
2
Arm Restraint Spring

5
TP15KF-032
4
Flat Washer

6
TP15KF-033
4
Spring Washer

7
TP15KF-034
4
Nut

8
TP15KF-024
4
Arm Restraint Engage Gear

9
8
Arm Restraint Plate

10
TP15KF-029
4
Arm Restraint Plunger

11
TP15KF-030
4
Pin

12
TP15KF-044
2
Bolt

13
TP15KF-042
8
Bushing

14
TP15KF-043
2
Self-Lock Nut

15
TP15KF-041
2
Pullback Spring

16
TP15KF-047
4
Bushing

17
TP15KF-039
2
Pull Rope

18
TP15KF-040
4
Bushing

19
TP15KF-038
2
Cover

20
TP15KF-036
2
Latch Release Pivot

21
TP15KF-037
2
Bolt

22
TP15KF-035
2
Safety Latch Weldment
