Hand Powered Pumps – Gasboy Consumer Series Pumps – 1200
1200 Series Rotary Register Hand Pump
Add toQuote
Add toOrder
Item
SVI Part #
OEM #
Description
7
BP-4214-21
051880
Screw
9
Request Details
030460
Hose
10
Request Details
038455
Nozzle, Auto-Shut Off (Opt.)
14
BP-4214-24
051895
Screw
18
Request Details
055497
Shaft Rotor Assy., 1200RT (incl. 20–22)
19
Request Details
055495
Shaft Rotor Assy., 1200 (incl. 21–23)
20
Request Details
055361
Pump Shaft, 1200RT
26
Request Details
051790
Screw
29
Request Details
049406
Retaining Ring
30
Request Details
052316
Screw
31
Request Details
003037
Register Adapter, Gal.
32
Request Details
028182
Idler Gear, Gal.
34
Request Details
027656
Cluster Gear, Gal or Ltr.
34
Request Details
028453
Cluster Gear, Full Ltr.
36
Request Details
055242
Shaft, Gal. or Ltr.
37
Request Details
022662
Register Cover, Gal. or Ltr.
37
Request Details
030836
Register Cover, Full Ltr.
38
Request Details
055692
Shaft and Gear, Gal. or Ltr.
38
Request Details
055268
Shaft and Gear, Full Ltr.
39
Request Details
012085
Reset Lever Bearing
41
Request Details
033821
Reset Lever
44
Request Details
048805
Detent Spring Retainer
53
Request Details
024315
R.H. W. Number Disc. Full Ltr.
54
Request Details
035380
Dial Face, Ltr.
54
Request Details
035381
Dial Face, Full Ltr.
56
Request Details
053605
Self-Tapping Screw
59
Request Details
052840
Screw
65
Request Details
065309
Totalizer Assembly, Full Ltr (incl. 66, 69–70)
66
Request Details
015775
Totalizer Bracket
69
Request Details
039866
Odometer, Gal/Ltr
69
Request Details
039867
Odometer, Full Ltr.
70
Request Details
049375
Retaining Ring
72
Request Details
053900
Self-Tapping Screw
74
Request Details
038725
Nut
75
See BP-4214-14
032935
See Crank Handle Assembly
76
Request Details
068605
Washer
77
Request Details
052525
Screw
80
Request Details
027852
Drive Gear, US, RT
81
Request Details
027851
Drive Gear, IMP, RT
82
Request Details
043450
Drive Gear, Ltr/Full Ltr, RT
83
Request Details
022766
Pump Cover Assembly, RT
84
Request Details
022765
Pump Cover Assembly, 1200
85
Request Details
010737
Lock Arm, RT
92
Request Details
045520
Pipe Nipple
95
Request Details
003405
Pump Case, 1200, 1200RT, 1200RTU, 1235, 1223
96
Request Details
053335
Set Screw
100
Request Details
003042
Register Adapter, Ltr/Full Ltr
101
Request Details
043210
Pin, Full Ltr.
103
Request Details
028452
Idler Gear, Full Ltr.
105
Request Details
055277
Shaft, Full Ltr.
106
Request Details
068490
Washer, SS, Full Ltr.
107
Request Details
028183
Idler Gear, Ltr.
108
Request Details
003406
Pump Case, 1230-7 (not shown)
*Note: Gasket 026830 was replaced with O-Ring 049011. All pumps with serial numbers higher than 1237594 should use the O-Ring.
