Parts for Wheeltronic 18405AF Kodiak

Above Ground / Surface Mount 4-Post Lifts – Wheeltronic – 18405AF

Add to
Quote
Add to
Order
Item
SVI Part #
OEM #
QTY
Description

1
BH-7800-20
4-0636
1
Power Post Tower
View
2
BH-7800-18
4-0630
3
Tower
View
3
BH-7800-15
4-0627
1
Front Crossmember
View
4
BH-7800-14
4-0626
1
Rear Crossmember
View
5
BH-7800-17
4-0629
1
L.H. Deck Weldment
View
6
BH-7800-16
4-0628
1
R.H. Deck Weldment
View
7
BH-7797-54
3-0680
2
Approach Ramp
View
8
F-FW-0750-USS
6-0738
2
Flat Washer, 3/4"
View
9
BH-7798-76
6-0115
2
Cotter Pin, 1/8" x 2"
View
10
BH-7795-75
2-1381
2
Approach Ramp Pin
View
11
BH-7795-74
2-1379
4
Sheave Cover
View
12
F-HC-0250-20-2000
6-0177
4
Hex Hd. Bolt, 1/4"-20 x 2"
View
13
BH-7792-65
1-1057
2
Manifold
View
14
F-LW-0250
6-0056
4
Lock Washer, 1/4"
View
15
F-HN-0250-20
6-0032
4
Hex Nut, 1/4"-20
View
16
BH-7804-49
6-1683
2
3/4" Hose Clamp
View
17
BH-7798-11
6-0297
2
Slf.-Thrd. Screw, #10 x 3/4"
View
18
BH-7795-04
2-0998
2
Front Wheelstop
View
19
F-LW-0500
6-0059
14
Lock Washer, 1/2"
View
20
F-HC-0500-13-1000
6-0045
6
Hex Hd. Bolt, 1/2"-13 x 1"
View
21
F-HN-0500-13
6-0035
8
Hex Nut, 1/2"-13
View
22
F-FW-0500-USS
6-0063
8
Flat Washer, 1/2"
View
23
Request Details
6-1694
8
Hex Hd. Bolt, 1/2" x 4-1/2"
24
BH-7790-19
2-0772
8
Glide Bearing
View
25
F-SS-0500-13-1000
6-0726
4
Set Screw, 1/2"-13 x 1"
