Parts for Rotary SPO12 500 Series (Main Lift)

Add to
Quote
Add to
Order
Item
SVI Part #
OEM #
QTY
Description

1
40124
Hex Head Cap Screw-Long Flanged (3/8”-16 NC x 3/4”)

2
N494-1
Rightg Overhead Column-Inner (5W0 Series)

2
N481-1
Right Overhead Weldment (Inner) - (500/5A0 Series)

3
N417-3
Stiffener Angle

3
N432
Limit Switch Assembly (3Ø)

3
N413
Limit Switch Assembly (1Ø)

4
FJ7444-8
Sheave Shaft

5
N417-1
Sheave

8
FJ7668
Branch Tee

9
40664
Flanged Locknut (3/8"-16NC)

11
N493-1
Left Overhead Column-Outer (5W0 Series)

11
N480-1
Left Overhead Weldment (Outer) - (500/5A0 Series)

12
N440
Column Mounting Bracket

14
FJ839
Overhead Hose-Low Ceiling MODEL (500/5A0 Series)

14
FJ843
Overhead Hose-Standard Height MODEL (500/5A0 Series)

14
FJ844
Overhead Hose-EH-1 MODEL (500/5A0/5W0 Series)

14
FJ845
Overhead Hose-EH-2 MODEL (500/5A0/5W0 Series)

15
N390
Equalizer Cables-Low Ceiling MODEL (500/5A0 Series)

15
N387
Equalizer Cables-Standard Height (500/5A0 Series)

15
N388
Equalizer Cables-EH-1 MODEL (500/5A0/5W0 Series)

15
N389
Equalizer Cables-EH-2 MODEL (500/5A0/5W0 Series)

16
41200
Cotter Pin Large (1/8” x 1”)

17
N467
Switch Bar Assembly (1Ø)

17
N434
Switch Bar Assembly (3Ø)

19
FJ7871
Spacer (3/4”)

20
40109
Hex Head Cap Screw (1/4”-20NC x 2”)

21
40743
Hex Nylon Insert Locknut (5/8”-11NC)

22
N495
Column Extension-Low Ceiling MODEL (500/5A0 Series)

22
N477
Column Extension-Standard Height MODEL (500/5A0 Series)

22
N478
Column Extension-EH-1 MODEL (500/5A0/5W0 Series)

22
N479
Column Extension-EH-2 MODEL (500/5A0/5W0 Series)

23
x
Carriage Bolt (3/8"-16NC x 1")

24
40183
Carriage Bolt Large (3/8"-16NC x 2-1/2")

25
FA7147-1
Capacitor Box

25
FA7203-1
Capacitor Box-Cover Plate

25
FA7205
Drum Switch

25
FA7205-1
Drum Switch-Handle

25
40275
Pan Head Machined Screw-Plated (M5 x 10)

27
FJ837
Power Unit Hose (500/5A0 Series)

27
N396
Power Unit Hose (5W0 Series)

28
P1391
Power Unit (Single Phase)

28
P1395
Power Unit (Three Phase)

28
P1360
Power Unit (575 Volt)

29
40670
Hex Nut (5/16”-18NC)

30
40854
External Tooth Lockwasher (5/16”)

31
40271
Bolt (5/16”-18NC x 1-1/2”)

32
N757
Right Column

33
N826
Carriage Yoke

34
N2154
Arm Pin

35
FJ7360
Slider Block

36
FJ7380
14
Wedge Anchor-All Thread (Box of 20 3/4" x 5-1/2")

37
40627
Zinc Hex Nut (1/4”-20NC)

38
40779
External Tooth Lockwasher (1/4”)

39
N383
Hose Clip

41
FF729
Spotting Wheel Dish Kit

42
N619
Cable End Bracket

43
N618
Cable Guide

44
40641
Flanged Locknut (1/4”-20NC)

45
40108
Hex Head Cap Screw-Grade 5 (1/4”-20NC x 1”)

46
x
2
Bleeder Screw (Rotary)

47
N380
Hydraulic Cylinder (68" Rise)

47
N382
Hydraulic Cylinder (71" Rise)

48
N754
Left Column Weldment

49
FJ7985-1
Actuator Pin Handle

50
N121-1
Actuator Pin

51
FJ7391-1
2
Approach Bumper (door-18” Lg)

52
FJ7391-2
Carriage Bumper

53
N2148
Arm Restraint Kit

54
14427
Spring Pin-Large Stainless (1/4" dia. x 1-1/2")

55
N2121
Arm Restraint Panel

56
FJ7656-2
Arm Restraint Spring

57
N119-3
Retaining Pin

58
40063
2
Pan Head Machine Screw Plated (1/4”-20NC x 3/8” Large)

59
N119-1
Sheave Cover

60
40696
Carriage Bolt-Large (3/8"-16NC x 3/4")

61
N1162-1
Tie Bar

62
N69
Latch Cable Guide

External Tooth Lockwasher (3/8”)
