Parts For Rotary SPO10 700 Series (Main Lift)

Add to
Quote
Add to
Order
Item
SVI Part #
OEM #
QTY
Description

1
FJ7444-8
Sheave Shaft

2
41388
Bushing (1-1/2" O.D. x .760-.770" I.D. x .045")

3
41411
Truarc Klipring (#5304-75 3/4" Shaft)

4
N377
Sheave

5
40124
Hex Head Cap Screw-Long Flanged (3/8" -16 NC x 3/4")

6
N383
Hose Clip

7
40664
Flanged Locknut (3/8" -16NC)

8
N481
Overhead Assembly-Inner (Right)

9
N480
Overhead Assembly-Outer (Left)

10
N2154
Arm Pin

11
N439
Column Mounting Bracket

12
FJ7600
Locking Latch Cable

13
N3103
Overhead Hose-Standard

14
N372
Equalizer Cables

15
40642
Insert Locknut (1/4" -20NC)

16
FJ7871
Spacer (3/4")

17
40779
External Tooth Lockwasher (1/4")

18
40627
Hex Nut-Zinc Coated (1/4" -20NC)

19
XXXX
Cutoff Switch Assembly

20
40795
Flat Washer (1/4")

21
40099
Hex Head Cap Screw (1/4" -20NC x 3/4")

22
N432-5
Actuator Assembly (3Ø)

23
41200
Cotter Pin (1/8” x 1” Lg. 3Ø)

24
N467
Switch Bar Assembly

25
40114
Hex Head Cap Screw (1/4" -20NC x 2-3/4")

26
40743
Nylon Insert Lock Nut (5/8" -11NC)

27
N470
Standard Column Extension

28
XXXX
Carriage Bolts (3/8" -16NC x 3/4")

29
N755
Standard Column (Right)

30
41672
Pan Head Machine Screw (M5 x 45)

30
FA7147-1
Capacitor Box

30
FA7364
Drum Switch

30
FA7364-1
Drum Switch Lever

30
FA7366-1
Capacitor Box Cover Plate

31
FJ7668
Tee Branch

32
FJ837
Power Unit Hose

33
XXXX
Power Unit

34
40678
Hex Flanged Lock Nut (5/16" -18NC)

35
40509
Hex Head Cap Screw-Flanged Full Thread (5/16" - 18NC x 1-1/2")

36
N822
Carriage Yoke

37
FF729
Wheel Spotting Dish Kit

38
FJ7360
Slider Block

39
FJ7380
Wedge Anchor-All Thread (3/4" x 5-1/2")

40
N619
Cable End Bracket

41
N618
Cable Guide

42
40641
Flanged Locknut (1/4" -20NC)

43
40108
Hex Head Cap Screw-Grade 5 (1/4" -20NC x 1")

44
XXXX
Bleeder Screw

45
N3156
Cylinder-Hydraulic (68" Rise)

45
N382
Cylinder-Hydraulic (71" Rise)

46
N752
Column Standard (Left)

47
FJ7985-1
Actuator Pin Handle

48
N121-1
Actuator Pin

49
FA941
Carriage Bumper

50
FJ7391-1
Approach Bumper

51
N2148
Arm Restraint Kit

52
14427
Spring Pin-Stainless (1/4" dia. X 1-1/2" Lg.)

53
N2121
Arm Restraint Pawl

54
FJ7656-2
Arm Restraint Spring

55
N119-3
Retaining Pin

56
40063
2
Pan Head Machined Bushing-Plated (1/4" -20NC x 3/8" Lg.)

57
N119-1
Sheave Cover

58
FJ7659-3
Front Shim

59
FJ716-6
Shim

60
doorjammer (24")

60
doorjammer (12")

61
Power Station (2-post)

62
N768
Column Seismic (Right)

63
N766
Column Seismic (Left)
