Parts for Rotary RJ9000

Add to
Quote
Add to
Order
Item
SVI Part #
OEM #
QTY
Description

1
FC5818-24
Left Sliding Adapter

2
FC576
Stop Bolt

3
FC5818-37
Right Sliding Adapter

4
FC5108
Auxiliary Adapter

5
FC579
Auxiliary Adapter

6
FC5185-67
Slider

7
FC5818-47
Upper Channel Assembly

8
FC5185-69
Guard Retainer

9
FC5185-68
Slider

10
2 req'd.
Socket Hd. & LW (3/8"-16NC x 3/8" lg.)

11
FC5818-30
Lock Dog

12
FC5818-25
Link Assembly

13
FC5818-18
Cylinder

14
FC5818-51
Upper Cylinder Pin

15
FC5185-45
Elbow Adapter

16
FC5960
Telescopic End Section

17
FC5144-1
Guard

18
FC5818-29
Pin

19
FC5818-12
Lower Channel Assembly

20
FC5954
Pump

21
4 req'd.
Self Tapping Screw (1/4"-20NC)

22
FC5895-8
Hose

23
FC5185-32
Lower Cylinder Pin

24
2 req'd
Spirol Pin (1/4" x 1" Lg.)

25
FC5960-4
Spring

26
FC5895-10
Axle

27
FC5895-7
Axle Support

28
FC5895-1
Roller
